Al Shakru Sheets and Plates is a well-regarded manufacturer and supplier based in Dubai, UAE, focusing on high-quality Alloy 20 Foils that are recognized for their exceptional resistance to corrosion, durability, and performance in aggressive chemical settings. These foils are precision-crafted to comply with international standards, guaranteeing they provide dependable strength and enduring stability for challenging industrial uses. Backed by a firm dedication to quality control and cutting-edge manufacturing methods, Al Shakru Sheets and Plates supplies Alloy 20 Foils that are ideal for essential operations across industries such as chemical processing, pharmaceuticals, food production, and power generation. The company remains devoted to delivering durable and efficient solutions that combine mechanical dependability with remarkable chemical resistance.
Alloy 20 Foils consist mainly of nickel, chromium, and iron, along with the addition of copper and molybdenum to enhance resistance to pitting, stress corrosion cracking, and oxidizing agents. Their standard composition includes 32–38% nickel, 19–21% chromium, 2–3% molybdenum, and 3–4% copper. These foils demonstrate a tensile strength of roughly 620 MPa and a yield strength of about 300 MPa. Furthermore, Alloy 20 Foils provide superb ductility, formability, and weldability, allowing them to preserve their structural integrity and mechanical performance even under demanding chemical and thermal conditions.
ASTM B463, ASME SB463
0.02mm – 5.0mm
3.2mm – 1500mm
NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA.
| STANDARD | WERKSTOFF NR. | UNS | AFNOR | EN |
| Alloy 20 | 2.4660 | N08020 | Z2NCUD31-20AZ | NiCr20CuMo |
| Grade | C | Mn | Si | S | Cu | Ni | Cr | Fe | Mo | P |
| Alloy 20 | 0.07 max | 2.00 max | 1.00 max | 0.035 max | 3.0-4.0 | 32.0-38.0 | 19.0-21.0 | 29.85 min* | 2.0-3.0 | 0.045 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30% |
We supply materials accompanied by both mill test certificates and third-party test certificates, guaranteeing top-tier quality and compliance.
Al Shakru Sheets and Plates, located in Dubai, UAE, is a top supplier and stockist of premium metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to satisfy our customers specific needs. With an emphasis on supplying superior products, we serve a broad array of industries, offering dependable solutions for varied applications. Our comprehensive inventory features Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
Alloy 20 foilsoffer many benefits, including outstanding corrosion resistance, especially in acidic settings like sulfuric acid. They resist pitting, crevice corrosion, and stress corrosion cracking exceptionally well, providing durability and dependability under severe conditions. Their excellent mechanical characteristics, including high tensile and yield strength, allow them to perform effectively under pressure and thermal stress. Furthermore, Alloy 20 foils are adaptable and simple to fabricate, making them well-suited for use in chemical processing, pharmaceuticals, food production, and other sectors that demand high-performance corrosion-resistant materials.
Yes,we provide custom dimensions for Alloy 20 Foils to fit particular project requirements. The team at Al Shakru Sheets and Plates is committed to delivering customized solutions for everything you need. To learn more, reach out to us at sales@alshakruplates.ae.
Alloy 20 Foils are widely applied across industries that require strong corrosion resistance and mechanical stability. They are especially fitting for producing equipment that makes contact with sulfuric acid, nitric acid, and other harsh chemicals, such as storage tanks, piping systems, and heat exchangers. Within chemical and pharmaceutical processing, these foils serve in reactors, vessels, and protective linings. Additionally, Alloy 20 Foils are also used in food and beverage processing, desalination plants, and power generation facilities where withstanding corrosion and chemical attack is essential. Their durability, reliability, and capacity to endure severe environments make them a vital selection for numerous applications.
