Al Shakru Sheets and Plates, a well-regarded manufacturer and supplier based in Dubai, UAE, focuses on premium Hastelloy C22 Sheet and Plates . These materials are renowned for their exceptional corrosion resistance, remarkable strength, and durability, even in the most demanding environments. Engineered to function dependably in both oxidizing and reducing chemical conditions, these sheets and plates deliver long-lasting performance in extreme industrial and marine applications. Al Shakru Sheets and Plates is dedicated to precision manufacturing, guaranteeing a superior surface finish and rigorous adherence to international quality standards. Backed by a strong reputation for delivering high-performance materials, Hastelloy C22 Sheet and Plates are ideal for critical engineering, chemical processing, and high-temperature uses that require outstanding structural integrity and corrosion resistance.
Hastelloy C22 Sheet and Plates are nickel-based alloys composed of Nickel (56–63%) , Chromium (20–22%) , and Molybdenum (12–14.5%) , together with small quantities of Tungsten, Iron, and Cobalt . They offer outstanding resistance to pitting, crevice corrosion, and to both oxidizing and reducing conditions. The material has a tensile strength of 485–690 MPa , a yield strength of 275–345 MPa , and good elongation, which combine to deliver superb toughness, ductility, and thermal stability for service in extremely corrosive and challenging industrial applications.
| Type | Plate, Sheet, Strip, Coils, Foils, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate |
|---|---|
| Grade | ASME SB575, ASTM B575 UNS N06022, AMS, MSRR, BS |
| ASTM B575 Alloy C22 Plate Length | 0-12mm or as required |
| Specification of Plate | ASTM B575 UNS N06022, ASME SB575, MSRR, BS, AMS 4544 sheet |
| UNS N06022 Plate Width | 0-2500mm or as required |
| Plate Thickness | 0.3 to 1200 mm or as required |
| Alloy C22Plate Process | Hot/ Cold Rolled |
| Plate surface | No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled ASTM B575 Alloy C22 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN | OR |
| Hastelloy C22 | 2.4602 | N06022 | NW 6022 | – | NiCr21Mo14W | – |
|
Stocked Sizes |
|
|---|---|
|
Size (in inches) |
Size (in mm) |
|
.125″ |
3.18mm |
|
.134″ |
3.40mm |
|
.156″ |
3.96mm |
|
.187″ |
4.75mm |
|
.250″ |
6.35mm |
|
.312″ |
7.92mm |
|
.375″ |
9.53mm |
|
.500″ |
12.7mm |
|
.600″ |
15.9mm |
|
.750″ |
19.1mm |
|
.875″ |
22.2mm |
|
1″ |
25.4mm |
|
1.125″ |
28.6mm |
|
1.250″ |
31.8mm |
|
1.500″ |
38.1mm |
|
1.750″ |
44.5mm |
|
2″ |
50.8mm |
|
2.500″ |
63.5mm |
|
3″ |
76.2mm |
We supply products that are accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Hastelloy C22 sheets and platesoffer exceptional benefits, making them well-suited for use in demanding environments. They deliver superb resistance to both oxidizing and reducing agents, guaranteeing protection against pitting, crevice corrosion, and stress corrosion cracking. Their adaptability enables them to function dependably in aggressive chemical processes, including acidic and chlorinated environments. Featuring high mechanical strength and remarkable durability, they are appropriate for high-temperature applications. Furthermore, Hastelloy C22 sheets and plates demonstrate superb weldability, ease of fabrication, and extended service life, lowering maintenance and boosting efficiency in challenging industrial operations.
| Thickness | Plate Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
Hastelloy C22 Sheet and Plates are used across a range of industries that demand outstanding corrosion resistance and mechanical dependability. Common uses include chemical processing equipment, reactor vessels, heat exchangers, flue gas scrubbers, marine components, and pollution control systems. They also serve the aerospace, petrochemical, and pharmaceutical sectors, where structural parts have to endure aggressive chemicals and elevated temperatures. Owing to their superb formability, weldability, and durability, Hastelloy C22 Sheet and Plates from Al Shakru Sheets and Plates are perfectly suited for manufacturing critical components, structural parts, and high-performance assemblies.
