Al Shakru Sheets and Plates, based in Dubai, UAE, has earned a strong reputation as a trusted manufacturer and supplier of Stainless Steel 316 Circles . These circles are known for their remarkable corrosion resistance, durability, and mechanical strength. Made from austenitic stainless steel containing molybdenum, they provide superior defense against pitting, crevice corrosion, and chemical attacks, particularly in chloride-heavy environments and marine conditions. Al Shakru Sheets and Plates is dedicated to precise manufacturing and strict quality control, making certain that their 316 circles satisfy the demanding requirements of industrial, architectural, and marine applications. Their products comply with international standards, ensuring reliable performance and enduring structural integrity even under the harshest conditions.
Stainless Steel 316 Circles consist of chromium (16–18%), nickel (10–14%), and molybdenum (2–3%), elements that markedly enhance their resistance to corrosion and their mechanical stability. They feature a tensile strength of roughly 515 MPa, a yield strength of 205 MPa, and an elongation of 40%. Having a density of 8.0 g/cm³ and a melting range of 1375–1400°C, these circles retain remarkable toughness, weldability, and formability, guaranteeing dependable performance in high-temperature and corrosive settings.
| Standard | ASTM A240, ASME SA240 |
| Dimensions | ASTM, ASME and API |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc. |
| Thickness | 1 Mm To 100 mm. |
| Diameter | Upto 2000 Mm. |
| Circle Diameter | 3″ DIA up to 38″ DIA 1500 lbs max. |
| Circles Form | Cold Rolled, Small Flat, Industrial, Proof Machined, Perforated, Forged Steel, Cnc Finish, Polished Unique, Hot Rolled Circle.. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
| Grades | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316 | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| Size | 18 G. | 19 G. | 20 G. | 22 G. | 24 G. | 26 G. |
| .4.5 | .0-107 | 0-085 | 0-080 | 0-062 | 0.049 | 0-040 |
| 5 | 0-120 | 0-095 | 0-090 | 0-070 | 0-055 | 0-045 |
| 5.5 | 0-146 | 0-119 | 0-109 | 0-085 | 0-066 | 0-054 |
| 6 | 0-172 | 0-136 | 0-130 | 0-100 | 0-079 | 0-064 |
| 6.5 | 0-200 | 0-153 | 0-150 | 0-128 | 0-093 | 0-074 |
| 7 | 0-235 | 0-190 | 0-176 | 0-136 | 0-107 | 0-088 |
| 7.5 | 0.270 | 0.212 | 0.201 | 0-157 | 0-123 | 0-100 |
| 8 | 0-307 | 0-240 | 0-230 | 0-180 | 0-140 | 0-115 |
| 8.5 | 0-347 | 0-270 | 0-262 | 0-202 | 0-156 | 0-130 |
| 9 | 0-388 | 0-330 | 0-301 | 0-230 | 0-178 | 0-145 |
| 9.5 | 0-472 | 0-342 | 0-324 | 0-252 | 0-198 | 0-162 |
| 10 | 0-480 | 0-380 | 0-360 | 0-280 | 0-220 | 0-180 |
| 11 | 0-580 | 0-450 | 0-435 | 0-338 | 0-266 | 0-218 |
| 12 | 0-690 | 0-540 | 0-518 | 0-403 | 0-318 | 0-253 |
| 13 | 0-811 | 0-640 | 0-508 | 0-608 | 0-371 | 0-304 |
| 14 | 0-940 | 0-750 | 0-708 | 0-558 | 0-430 | 0-352 |
| 15 | 1-080 | 0-860 | 0-808 | 0-650 | 0-495 | 0-405 |
| 16 | 1-228 | 0-960 | 0-921 | 0-736 | 0-563 | 0-460 |
| 17 | 1-382 | 1-080 | 0-940 | 0-809 | 0-635 | 0-560 |
| 18 | 1-595 | 1-200 | 1-116 | 0-907 | 0-712 | 0-683 |
| 19 | 1-732 | 1-350 | 1-300 | 1-010 | 0-794 | 0-750 |
| 20 | 1-920 | 1-400 | 1-340 | 1-120 | 0-880 | 0-785 |
Our products are supplied with mill test certificates as well as third-party test certificates, guaranteeing top-tier quality and compliance.
Stainless steel 316 circleoffers several benefits, including outstanding corrosion resistance, particularly against chloride and salt water, which makes it perfect for marine, chemical and high-arm environmental Snakes strong tensile strength, durability and the capacity to endure extreme temperatures to guarantee long-term performance . Its superb weldability and formability allow it to be manufactured easily into a range of shapes. SS 316 is non-reactive, providing hygiene and safety in sectors like food processing and pharmaceuticals. Furthermore, it withstands pitting, crack corrosion and oxidation, leading to reduced maintenance costs and greater durability under extreme conditions.
Stainless Steel 316 Circles are used across a wide range of applications where both resistance to corrosion and structural strength are required. They frequently appear in chemical processing equipment, marine components, heat exchangers, and machinery serving food or pharmaceutical processing. They also serve architectural and industrial frameworks, pressure vessels, and offshore platforms in which withstanding acids, chlorides, and oxidizing environments is critical. Their outstanding longevity and reliability make them ideal for fabrication, structural, and high-performance engineering work under demanding operating conditions.
