Al Shakru Sheets and Plates, a premier manufacturer and supplier based in Dubai, UAE, focuses on high-quality Monel K500 Foils engineered to endure harsh conditions with exceptional corrosion resistance, strength, and durability. Manufactured to comply with rigorous international standards, these nickel-copper alloy foils feature accurate thickness, an excellent surface finish, and dependable mechanical performance. By combining advanced production techniques with rigorous quality control, Al Shakru Sheets and Plates guarantees products that are both dependable and high-performing. They serve a range of industries, such as aerospace, marine, chemical processing, and oil and gas, offering Monel K500 Foils ideally suited for applications requiring structural integrity, resistance to corrosive environments, and lasting performance even under extreme conditions.
Monel K500 Foils are composed primarily of nickel (roughly 63–70%) and copper (about 28–34%), along with minor quantities of aluminum and titanium included to enable age-hardening. These foils demonstrate notable tensile strength in the range of 860–1100 MPa, yield strength from 345–690 MPa, and outstanding ductility. They deliver superior corrosion resistance to seawater, acids, and alkalis, while also retaining strong mechanical stability and toughness at high temperatures. This distinctive blend of strength, flexibility, and durability makes Monel K500 Foils well-suited for challenging industrial, chemical, and structural applications.
| Standards | ASTM B127 / ASME SB127 |
| Thickness | 0.3 – 10.0mm & AS PER CUSTOMER’S REQUIREMENT |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm & AS PER CUSTOMER’S REQUIREMENT. |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm & AS PER CUSTOMER’S REQUIREMENT. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard AS PER CUSTOMER’S REQUIREMENT. |
| Test Certificate | Chemical test, Fitting test, Alloy test, Radiography test, Macro and micro-test, Hydrostatic test, Impact test. |
| Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled (HR), Cold rolled (CR), SATIN (Met with Plastic Coated) etc. |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
DIN 2.4375 Foilsoffer many benefits, such as superior strength and outstanding resistance to corrosion, particularly in marine environments, acids, and alkalis. Their high tensile and yield strength provide durability and reliability when subjected to extreme stress and high temperatures. Monel K500 foils also demonstrate exceptional resistance to stress corrosion cracking, pitting, and oxidation, which makes them perfect for use in demanding conditions. Furthermore, they retain excellent mechanical properties at elevated temperatures. Their easy fabrication and welding further boost their versatility, making them well-suited for applications in aerospace, chemical processing and marine industries.
| STANDARD | WERKSTOFF NR. | UNS | AFNOR | JIS | GOST | BS | EN |
| Monel k500 | 2.4375 | N05500 | – | – | – | – | – |
Monel K500 Foils are widely applied in industries demanding high strength, corrosion resistance, and thermal stability. They are frequently employed in marine components, fasteners, and thin-walled structural parts . Within the chemical processing and oil & gas sectors , they play a vital role in reactors, heat exchangers, and piping systems . Their exceptional resistance to seawater, acids, and alkalis further makes them an excellent option for aerospace components, industrial machinery, and precision engineering applications . Monel K500 Foils ensure enduring durability, dimensional stability, and reliable mechanical performance in challenging environments.
