Al Shakru Sheets and Plates, a well-regarded manufacturer and supplier based in Dubai, UAE, focuses on premium Stainless Steel Angles engineered for outstanding strength, durability, and corrosion resistance. These angles are made using advanced manufacturing methods that comply with international quality standards, guaranteeing dependable performance in a wide range of applications. Celebrated for their excellent weldability, formability, and capacity to endure harsh conditions, the Stainless Steel Angles from Al Shakru Sheets and Plates are ideal for structural, industrial, and architectural projects. Thanks to their accurate dimensions and clean finish, they deliver lasting reliability whether installed indoors or outdoors.
Stainless Steel Angles are made mostly of iron, combined with 16–20% chromium, 8–12% nickel, and minor quantities of elements such as carbon, manganese, and silicon. This distinctive makeup gives them outstanding resistance to corrosion, oxidation, and scaling. They feature a tensile strength between 515–620 MPa, a yield strength ranging from 205–310 MPa, and excellent elongation characteristics. Owing to their high toughness, stability, and formability, Stainless Steel Angles hold up well across different temperatures and mechanical loads, making them well-suited for both structural and high-temperature applications.
| Specifications | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 201 Angle | 5mm to 9mm |
| Thickness | 3.0mm – 120mm |
| Length | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | C | Mn | Si | P | S | Cr | Ni | N |
| SS 201 | 0.15 max | 5.5 – 7.5 | 100 max | 0.06 max | 0.03 max | 16.00-18.00 | 0.3 – 0.5 | – |
| Temper | Tensile Strength | Yield Strength | Elongation | Rockwell | ||
|---|---|---|---|---|---|---|
| KSi | MPa | KSi | MPa | in 2 inches % | ||
| 1/2 Hard | 150 | -1034 | 110 | -758 | 10 | C-32 |
| 1/4 Hard | 125 | -862 | 75 | -517 | 20 | C-25 |
| 3/4 Hard | 175 | -1207 | 135 | -931 | 7 | C-37 |
| Annealed | 95 | -655 | 45 | -310 | 40 | B-90 max. |
| Full Hard | 185 | -1276 | 140 | -965 | 5 | C-41 |
| STANDARD | UNS | WERKSTOFF NR. |
| SS 201 | S20100 | 1.4372 |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Stainless steel angleoffer numerous benefits, making them favored in construction and manufacturing. They are extremely strong, resistant to corrosion, and stay strong even under extreme temperatures. Stainless steel corners also provide great visual appeal thanks to their refined design. Little maintenance is needed to guarantee durability. Furthermore, their adaptability, ease of production, and strength-to-weight ratio make them perfect for construction uses. Their resistance to severe chemical and environmental conditions guarantees dependability and efficiency across the automotive, marine and construction industries.
| Width (mm) | Thickness (mm) | Width (Inches) | Thickness (Inches) |
|---|---|---|---|
| 20 x 20 | 3 to 5 | 3/4″ | 1/8 to 1/4 |
| 25 x 25 | 3 to 5 | 1″ | 1/8 to 1/4 |
| 30 x 30 | 3 to 5 | 1.1/8 | 1/8 to 1/4 |
| 32 x 32 | 3 to 6 | 1.1/4 | 1/8 to 1/4 |
| 35 x 35 | 3 to 6 | 1.3/8 | 1/8 to 1/4 |
| 38 x 38 | 3 to 6 | 1.1/2 | 1/8 to 1/4 |
| 40 x 40 | 3 to 6 | 1.5/8 | 1/8 to 1/4 |
| 45 x 45 | 3 to 6 | 1.3/4 | 1/8 to 1/4 |
| 50 x 50 | 3 to 6 | 2″ | 1/8 to 1/4 |
| 60 x 60 | 5 to 6 | 2.3/8 | 3/16 to 1/4 |
| 65 x 65 | 5 to 6 | 2.1/2 | 3/16 to 1/4 |
| 70 x 70 | 5 to 6 | 2.3/4 | 3/16 to 1/4 |
| 75 x 75 | 5 to 6 | 3″ | 3/16 to 1/4 |
Stainless Steel Angles are widely applied across construction, marine, petrochemical, and manufacturing industries. They serve as structural supports in buildings, bridges, and machinery, delivering vital strength and stability. Within architectural settings, they are used for frameworks, brackets, trims, and railings, owing to their resistance to corrosion and attractive finish. In industrial applications, Stainless Steel Angles are used in equipment fabrication, conveyors, and support structures. Their combination of durability, fabrication ease, and enduring resistance to environmental challenges makes them a superb option for a broad spectrum of engineering and construction requirements.
