Al Shakru Sheets and Plates distinguishes itself as a premier manufacturer and supplier of Duplex Steel Sheets and Plates based in Dubai, UAE . We take pride in supplying superior-quality duplex steel products that are renowned for their outstanding strength, corrosion resistance, and lasting durability. Our Duplex Steel Sheets and Plates are made with precision, employing advanced manufacturing techniques and rigorous quality control practices to ensure uniform thickness, a smooth finish, and reliable performance. These sheets and plates are ideal for marine, chemical, and industrial applications, combining mechanical strength with an exceptional capacity to withstand stress corrosion cracking.
Al Shakru Sheets and Plates serves a range of industries, including oil and gas, chemical processing, marine engineering, and industrial manufacturing, delivering solutions that meet international standards for durability and reliability.
Duplex Steel Sheets and Plates feature a well-balanced austenitic (≈50%) and ferritic (≈50%) stainless steel microstructure , enhanced with alloying elements such as chromium (20–25%), nickel (4–6%), molybdenum (2–3%), nitrogen, and trace elements . They deliver impressive tensile strength (≈650–800 MPa) , yield strength (≈450–550 MPa) , notable ductility , and outstanding resistance to pitting, crevice corrosion, and stress corrosion cracking , making them well-suited for demanding and corrosive environments.
| Specifications | ASTM A240 / ASME SA 240 |
| Duplex Steel Plate Grades | 2205, 2507 |
| Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Width | 10-2500mm |
| Length | 2m,2.44m, 3m as per requirement |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | Cold rolled sheet (CR), Hot rolled plate (HR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| MN | C | SI | S | P | CR | NI | MO | N |
|---|---|---|---|---|---|---|---|---|
| 2.0 max | 0.03 max | 1.0 max | 0.02 max | 0.03 max | min: 21.0 max: 23.0 | min: 4.5 max: 6.5 | min: 2.5 max: 3.5 | min: 0.08 max: 0.20 |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Duplex Steel Sheets and Platesoffer many benefits, such as greater strength, strong resistance to corrosion, and outstanding durability in harsh conditions. The blend of austenitic and ferritic microstructures delivers improved resistance to stress corrosion cracking, pitting, and crevice corrosion. They are recognized for their high tensile strength, which makes them well-suited for high-pressure and high-temperature uses. Moreover, Duplex Steel provides excellent weldability and formability, making it appropriate for a broad array of industries, such as oil and gas, chemical, marine, and structural applications. Its affordability further enhances its appeal.
| Thickness (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) |
| 5 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 6 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 8 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 10 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 12 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 15 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 16 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 20 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 25 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 30 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 35 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 40 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 45 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 50 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 60 | 4000 x 2000 | ||||
| 70 | 4000 x 2000 | ||||
| 80 | 4000 x 2000 | ||||
| 90 | 4000 x 2000 | ||||
| 100 | 4000 x 2000 |
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
| 2H – Work hardened | 0.4–6.35 | max. 1524 |
| Polished, brushed | 0.5–4.0 | max. 1524 |
These Duplex Steel Sheets and Plates are widely used in chemical processing equipment, heat exchangers, marine structures, offshore platforms, and pressure vessels because of their exceptional corrosion resistance and high strength-to-weight ratio. Within industrial and fabrication settings , they serve as structural supports, machinery components, and precision-engineered parts where durability, reliability, and lasting performance are critical. Additionally, these sheets and plates are essential to oil and gas, desalination, and renewable energy projects , delivering operational efficiency, minimal maintenance, and an extended service life.
