Al Shakru Sheets and Plates, a well-regarded manufacturer and supplier based in Dubai, UAE, focuses on premium Nickel Alloy 200 Foils engineered to perform exceptionally in corrosion resistance, high-temperature environments, and mechanical strength. These foils are produced to satisfy stringent international standards, guaranteeing uniform thickness, an excellent surface finish, and reliable durability for even the toughest industrial uses. By combining advanced manufacturing methods with rigorous quality control, Al Shakru Sheets and Plates supplies accurate and high-performance nickel alloy products. The company serves a range of industries, such as chemical processing, aerospace, electronics, and marine engineering, offering Nickel Alloy 200 Foils ideally suited for settings that demand resistance to caustic conditions, oxidation, and thermal stress, all while delivering enduring reliability and performance.
Nickel Alloy 200 Foils consist chiefly of high-purity nickel (≥99.0%), together with minor quantities of iron, copper, carbon, and silicon. They feature a tensile strength of about 380–500 MPa, yield strength of 100–300 MPa, and impressive ductility. These foils deliver excellent corrosion resistance in reducing and caustic settings, hold their form under thermal stress, and supply good electrical and thermal conductivity. Their distinctive combination of strength, formability, and durability makes Nickel Alloy 200 Foils well suited for demanding industrial, high-temperature, and chemical applications that call for long-term reliability.
Specifications :ASTM B168 / ASME SB168
Size :1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm
Form :Foils, Rolls
Thickness :0.1mm to 12 mm Thk
Hardness :Soft, Hard, Half Hard, Quarter Hard, Spring Hard and so on.
Finish :Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated)
Other services :Heat treatment, Annealing, Pickling, Polish, Electroplating, Anodizing, Rolling, Cutting, Forging, and more.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 200 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 200 | 2.4066 | N02200 | NW 2200 | NA 11 | НП-2 | N-100M | Ni 99.2 |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Nickel Alloy 200 foils deliver superb resistance to corrosion, particularly against alkalis, acids, and a range of chemicals, which makes them perfect for demanding conditions. Recognized for their strong thermal and electrical conductivity, these foils see broad use in areas such as electrical components and heat exchangers. They feature remarkable mechanical qualities, such as strength and flexibility, enabling easy fabrication. Furthermore, Nickel Alloy 200 foils show solid weldability and formability, which makes them well-suited for a variety of industrial uses, including aerospace, chemical processing, and marine environments. Their steadiness at high temperatures adds even more to their reliability.
Nickel Alloy 200 Foils are widely applied in industries demanding outstanding corrosion resistance, thermal stability, and mechanical performance. They are commonly used in chemical processing equipment, caustic evaporators, and reaction vessels. Within the electronics and aerospace sectors, they function as electrical connectors, battery components, and high-temperature structural elements. Their remarkable performance in reducing, caustic, and high-temperature conditions also makes them well suited for marine, petrochemical, and other demanding applications.
