Al Shakru Sheets and Plates, a leading manufacturer and supplier based in Dubai, UAE, focuses on premium Inconel Foils engineered to deliver outstanding strength, corrosion resistance, and performance in high-temperature environments. These carefully manufactured foils are made under rigorous quality control procedures to ensure even thickness, a smooth surface finish, and dependable mechanical properties. Ideal for challenging industries such as aerospace, chemical processing, power generation, and marine engineering, Al Shakru Sheets and Plates’ Inconel Foils provide trustworthy performance even under the harshest conditions. Their distinctive combination of durability, thermal stability, and corrosion resistance makes them indispensable for applications where safety, lasting reliability, and high performance cannot be compromised.
Inconel Foils are composed primarily of nickel (roughly 72%), chromium (about 14–17%), and iron (around 6–10%) , together with minor quantities of molybdenum, niobium, and titanium. They offer tensile strength ranging from 690–980 MPa , notable creep resistance, and outstanding oxidation resistance under high temperatures. Even in severe thermal and corrosive conditions, these foils maintain their mechanical integrity and dimensional stability. Thanks to their high strength, toughness, and scaling resistance, they are well suited for precise, high-performance uses throughout a range of industrial sectors.
| Grades | Nickel 200, Nickel 201, Monel 400, Monel K500, Inconel 600, Inconel 601, Inconel 625, Inconel 718, Incoloy 800 / 800H / 800HT, Incoloy 825, Hastelloy C22, Hastelloy C276, Hastelloy B2, Hastelloy B3, Hastelloy X |
| Thickness | 0.02mm -6mm |
| Width | 4mm -40mm |
| Length | AS PER CUSTOMER’S REQUIREMENT |
| Type of Material | HIGH NICKEL ALLOY SOFT, DEEP DRAW, EXTRA DEEP DRAW, QUARTER HARD, HALF HARD, FULL HARD. |
| Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
| Make | JINDAL STAINLESS STEEL, BAHRU, POSCO KOREA, POSCO THAINOX, COLUMBUS, ACERINOX, APERAM, TISCO, NISSHIN, NIPPON AND MANY MORE MILLS. |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.47 g/cm3 | 1413 °C (2580 °F) | 655 MPa, 95000 psi | 310 MPa, 45000 psi | 45 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Inconel Foils | N06600 | 2.4816 | NC15FE11M | NiCr15Fe | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | ЭИ868 |
We supply products accompanied by mill test certificates as well as third-party test certificates, guaranteeing the highest levels of quality and compliance.
Al Shakru Sheets and Plates, located in Dubai, UAE, is a top supplier and stockist of premium metal products, such as Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to fulfill our customers specific needs. With an emphasis on supplying high-grade products, we serve a broad array of industries, offering dependable solutions for varied applications. Our comprehensive inventory features Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
Inconel foilsInconel foils deliver remarkable benefits thanks to their high-performance nickel-based alloy makeup. They demonstrate outstanding resistance to corrosion, oxidation, and elevated-temperature environments, which makes them well suited for severe conditions. These foils preserve their mechanical strength and stability at temperatures above 1000°C. What’s more, they are highly resistant to stress corrosion cracking, pitting, and crevice corrosion. Their superb weldability and formability boost their versatility across applications like aerospace, chemical processing, and marine industries. Inconel foils are likewise long-lasting, guaranteeing extended service life and dependability in tough environments, while cutting maintenance costs and downtime.
Yes,we provide bespoke dimensions for Inconel Foils to satisfy particular project requirements. The team at Al Shakru Sheets and Plates is committed to delivering customized solutions for everything you need. To learn more, reach out to us at sales@alshakruplates.ae.
| Size (mm) | Weight per (Kg) |
Size (mm) | Weight per (Kg) |
|---|---|---|---|
| 2000 x 1000 x 2.0 | 32.7 | 2000 x1000 x 0.9 | 14.7 |
| 3000 x 1500 x 1.5 | 55.3 | 2500 x1250 x 0.7 | 17.9 |
| 3000 x 1500 x 2.0 | 73.7 | 2000 x1000 x 1.0 | 16.4 |
| 2500 x 1250 x 1.5 | 38.4 | 2000 x1000 x 0.7 | 11.5 |
| 3000 x 1500 x 3.0 | 112.0 | 2000 x1000 x 1.5 | 24.6 |
| 2500 x 1250 x 2.0 | 51.2 | 2500 x1250 x 0.9 | 23.0 |
| 2000 x 1000 x 2.5 | 40.9 | 2500 x1250 x 1.0 | 25.6 |
| 2500 x 1250 x 2.5 | 63.9 | 3000 x1500 x 1.0 | 36.8 |
| 2500 x 1250 x 3.0 | 77.5 | 3000 x1500 x 1.2 | 44.2 |
| 3000 x 1500 x 2.5 | 92.1 | 2000 x1000 x 1.2 | 19.6 |
| 2000 x 1000 x 3.0 | 49.6 | 2500 x1250 x 1.2 | 30.7 |
Inconel Foils are widely applied wherever heat and corrosion resistance are required, including aerospace components, turbine seals, gaskets, heat exchangers, and chemical processing equipment . They also serve the marine and petrochemical industries for high-temperature tubing, thermal insulation layers, and protective barriers . Within the electronics and energy sectors, Inconel Foils deliver dependable performance in fuel cells, battery components, and high-temperature mechanical assemblies . Their exceptional behavior under extreme temperatures and corrosive conditions ensures lasting durability, dimensional stability, and safe operation.
